Appliances Cables
60227IEC 56(RVV-90)60227IEC 56(RVV-90)
Product Certification:
CCC
Basic Parameters：
Rated Voltag:
300/300V
Rated The Working Temperature:
70℃
Executive Standard:
GB/T 5023
Conductor Structure：
Conductor Material：
Bare Stranded Copper
Insulation Material:
PVC
Jacket Material：
PVC
Product Properties：
1. High conductivity;
2. High electric insulation performance;
3. The cable is flexible and has excellent bending resistance;
4. It is of anti-interference capability, and can ensure effective and safe transmission of data.
Application：
The cables are used as electrical connected line in power installation, household appliances, electrically operated tools rated
voltage A.C 300/300V or below.
| Type | No.of Cores | Section(mm2) |
|
60227IEC56(RVV-90) |
2-3 |
0.5-.075 |
Appliances Cables
RVVRVV
Product Certification:
CCC
Basic Parameters：
Rated Voltag:
300/500V
Rated The Working Temperature:
70℃
Executive Standard:
GB/T 5023
Conductor Structure：
Conductor Material：
Bare Stranded Copper
Insulation Material:
PVC
Jacket Material：
PVC
Product Properties：
1. High conductivity;
2. High electric insulation performance;
3. The cable is flexible and has excellent bending resistance;
4. It is of anti-interference capability, and can ensure effective and safe transmission of data.
Application：
The cables are used as electrical connected line in power installation, household appliances, electrically operated tools rated
voltage A.C 300/500V or below.
| Type | No.of Cores | Section(mm2) |
|
RVV |
2 |
1.5-10 |
|
RVV |
3-5 |
4-10 |
|
RVV |
6-10 |
0.75-2.5 |
|
RVV |
10, 12, 2 |
0.5 |
|
RVV |
12-41 |
0.75-1.0 |
|
RVV |
2-38 + 1 |
0.75 + 2.0 |
Appliances Cables
60227IEC 53(RVV)60227IEC 53(RVV)
Product Certification:
CCC
Basic Parameters：
Rated Voltag:
300/500V
Rated The Working Temperature:
70℃
Executive Standard:
GB/T 5023
Conductor Structure：
Conductor Material：
Bare Stranded Copper
Insulation Material:
PVC
Jacket Material：
PVC
Product Properties：
1. High conductivity;
2. High electric insulation performance;
3. The cable is flexible and has excellent bending resistance;
4. It is of anti-interference capability, and can ensure effective and safe transmission of data.
Application：
The cables are used as electrical connected line in power installation, household appliances, electrically operated tools rated
voltage A.C 300/500V or below.
| Type | No.of Cores | Section(mm2) |
|
60227IEC 53(RVV) |
2-5 |
0.75-2.5 |
Appliances Cables
60227IEC52(RVV)60227IEC52(RVV)
Product Certification:
CCC
Basic Parameters：
Rated Voltag:
300/300V
Rated The Working Temperature:
70℃
Executive Standard:
GB/T 5023
Conductor Structure：
Conductor Material：
Bare Stranded Copper
Insulation Material:
PVC
Jacket Material：
PVC
Product Properties：
1. High conductivity;
2. High electric insulation performance;
3. The cable is flexible and has excellent bending resistance;
4. It is of anti-interference capability, and can ensure effective and safe transmission of data.
Application：
The cables are used as electrical connected line in power installation, household appliances, electrically operated tools rated
voltage A.C 300/300V or below.
| Type | No.of Cores | Section(mm2) |
|
60227IEC52(RVV) |
2-3 |
0.5-0.75 |
Appliances Cables
RVVPRVVP
Product Certification:
CCC
Basic Parameters：
Rated Voltag:
300/300V
Rated The Working Temperature:
70℃
Executive Standard:
JB/T 8734
Conductor Structure：
Conductor Material：
Bare Stranded Copper
Insulation Material:
PVC
Jacket Material：
PVC
Product Properties：
1. High conductivity;
2. High electric insulation performance;
3. The cable is flexible and has excellent bending resistance;
4. It is of anti-interference capability, and can ensure effective and safe transmission of data.
Application：
The cables are used as electrical connected line in power installation, household appliances, electrically operated tools rated
voltage A.C 300/300V or below.
| Type | No.of Cores | Section(mm2) |
|
RVVP |
1-12、16 |
0.3-2.5 |
|
RVVP |
20、26 |
0.5 |
Appliances Cables
H05Z1Z1-FH05Z1Z1-F
Product Series:
APPLIANCES CABLES
Basic Parameters：
Rated Voltag:
300/500V
Rated The Working Temperature:
70℃
Executive Standard:
HD 21.14S1
Product Properties：
1. The V0 Grade high insulation material is adopted to prevent flame and ensure safety;
2. The brand new highly insulating material is adopted to prevent electric leakage and ensure safety;
3. The brand new anti-aging material is adopted to prolong the service life and improve safety;
Application：
The cables are used as electrical connected line or wiring in power installation, household appliances, electrically operated tools, onstruction lighting and machines inner rated voltage A.C 300/500V or below.
| Type | No.of Cores | Section(mm2) |
|
H05Z1Z1-F |
2-5 |
0.75-4.0 |
Appliances Cables
H03Z1Z1-FH03Z1Z1-F
Product Certification:
VDE Certification
Basic Parameters：
Rated Voltag:
300/300V
Rated The Working Temperature:
70℃
Executive Standard:
HD 21.14S1
Product Properties：
1. The V0 Grade high insulation material is adopted to prevent flame and ensure safety;
2. The brand new highly insulating material is adopted to prevent electric leakage and ensure safety;
3. The brand new anti-aging material is adopted to prolong the service life and improve safety;
Application：
The cables are used as electrical connected line or wiring in power installation, household appliances, electrically operated tools, onstruction lighting and machines inner rated voltage A.C 300/300V or below.
| Type | No.of Cores | Section(mm2) |
|
H03Z1Z1-F |
2-4 |
0.5-0.75 |
Appliances Cables
H05Z1Z1H2-FH05Z1Z1H2-F
Product Series:
APPLIANCES CABLES
Basic Parameters：
Rated Voltag:
300/500V
Rated The Working Temperature:
70℃
Executive Standard:
HD 21.14S1
Product Properties：
1. The V0 Grade high insulation material is adopted to prevent flame and ensure safety;
2. The brand new highly insulating material is adopted to prevent electric leakage and ensure safety;
3. The brand new anti-aging material is adopted to prolong the service life and improve safety;
Application：
The cables are used as electrical connected line or wiring in power installation, household appliances, electrically operated tools, onstruction lighting and machines inner rated voltage A.C 300/500V or below.
| Type | No.of Cores | Section(mm2) |
|
H05Z1Z1H2-F |
2 |
0.75-1.0 |
